| This chiller automatically and precisely controls the water temperature between 5~30°, and delivers sufficient water quantity and high pressure (max 5.5Kg/cm2) for outstanding heat exchange.
It is safe and convenient to use with a built-in self-diagnosis and preliminary decision-making function. It comes in air cooling and water cooling types.
|
| |
 |
|
 |
|
|
 |
Fast cooling speed with a design for eliminating pipeline load and presser back, along with the implementation of the Bernoulli Principle |
|
Built-in self-diagnosis and preliminary decision-making function for self-diagnosis on all problems and cooling capacity |
|
Designed based on A.I. control system in order to obtain outstanding cooling |
|
|
| |
|
Voltage
V(Hz) |
Service Temp.
℃ |
Cooling
Media |
Comp.
Capa.
Kw(Hp) |
Cooling Capa.
Kcal/h |
Pump.
Capa.
Kw |
Pump.
Capa.
ℓ/min |
Pressure
Kg/㎠ |
Tank Capa.
ℓ |
Size
(W×L×H)
cm |
Weight
Kg |
MS-
CH10W/A |
220/380/
440
(60)/(50) |
+5 to
+30 |
FREON
R-22 |
0.75(1) |
2,980/3,320 |
0.75 |
75 |
1.5~3.8 |
40 |
40×60×55 |
180 |
MS-
CH30W/A |
2.2(3) |
8,790/9,550 |
0.75 |
75 |
1.5~3.8 |
60 |
60×90×82 |
250 |
MS-
CH50W/A |
3.8(5) |
13,800/15,800 |
0.75 |
75 |
1.5~3.8 |
60 |
60×90×82 |
250 |
MS-
CH75W/A |
5.5(7.5) |
21,500/23,860 |
1.50 |
150 |
2.5~4.2 |
80 |
60×90×82 |
320 |
MS-
CH100W/A |
7.5(10) |
28,650/31,500 |
1.50 |
150 |
2.5~4.2 |
120 |
75×140×160 |
460 |
MS-
CH150W/A |
11(15) |
38,800/42,000 |
2.20 |
240 |
1.5~3.8 |
120 |
75×140×160 |
610 |
MS-
CH200W/A |
15(20) |
58,500/61,000 |
3.75 |
340 |
1.5~3.8 |
140 |
100×180×180 |
570 |
MS-
CH300W/A |
22.5(30) |
88,500/91,000 |
3.75 |
340 |
1.5~3.8 |
160 |
100×210×185 |
720 |
MS-
CH400W/A |
30(40) |
117,500/120,000 |
5.62 |
460 |
1.5~3.8 |
200 |
100×210×185 |
700 |
MS-
CH500W/A |
37.5(50) |
147,500/150,000 |
5.62 |
460 |
1.5~3.8 |
300 |
110×220×190 |
850 |
| TYPE |
|
Air/Water |
|
|
|
|
|
|
|
| |
|
|
|
|
